Stator Honda XR250R OEM 31120-KT1-004

Stator

1995 Honda XR 250 R

1994 Honda XR 250 R

1993 Honda XR 250 R

1992 Honda XR 250 R

1991 Honda XR 250 R

1990 Honda XR 250 R

1989 Honda XR 250 R

1988 Honda XR 250 R

1987 Honda XR 250 R

1986 Honda XR 250 R

OEM 31120-KT1-004

Dimensions:

Interior diameter: 35 mm

Exterior diameter: 93 mm

Thickness: 18 mm

Length of wires stator to grommet: 85 mm

Length of wires grommet to plug: 485 mm

Other specifications:

Number of wires: 3

Number of plugs: 3

Number of pins: 3

Number of poles: 8

Wire to wire resistance:

Alternator: Yellow to Pink = 1 ohm +-20%

Alternator: Yellow to ground = O.L

Source: Black/Red to Ground = 129 ohms +-20%

Check the dimensions carefully
