Stator Honda XR200R OEM 31120-KT0-831 31120-KT0-830

CARMS010-104201

New product

OEM 31120-KT0-831 31120-KT0-830

More details

4 Items

7-8 Days

119,00 € tax incl.

The minimum purchase order quantity for the product is 4

More info

Stator Denso

Resistant to 200 degrees Celsius

1990-2002  HONDA XR200R

OEM 31120-KT0-831 31120-KT0-830

Dimensions :
Interior diameter : 36 mm
Exterior diameter : 96 mm
Thickness : 37 mm
Length of wires stator to grommet : 30 mm
Length of wires grommet to plug : 645 mm
Other specifications :
Number of wires : 3
Number of plugs : 3
Number of pins : 3
Number of poles : 8
Wire to wire resistance :
Alternator : Yellow to pink = 0.4 ohms +-20%
Alternator to ground = O.L
Source : Black/red to ground = 350 ohms +-20%
