Stator Yamaha Enticer 340 LT LTR Enticer 400 Excel III 340 VK540 OEM 83R-85560-M0-00

Stator

1991 Yamaha VK 540

1990 Yamaha VK 540

1990 Yamaha Enticer 400

1989 Yamaha VK 540

1989 Yamaha Enticer 400

1988 Yamaha VK 540

1988 Yamaha Excel III 340

1988 Yamaha Enticer 340 LTR

1988 Yamaha Enticer 340 LT

1988 Yamaha Enticer 340

1987 Yamaha Excel III 340

1987 Yamaha Enticer 340 LT

1987 Yamaha Enticer 340

OEM 83R-85560-M0-00

This stator assembly uses the following coils:

Charge Coil: 81L-85520-M0-00

Lighting Coils: 82H-81313-M0-00 & 81L-81314-M0-00

Pickup/Pulsar Coil: 8R4-85580-M0-00

Dimensions:

Interior diameter: 35 mm

Exterior diameter: 127 mm

Thickness: 50 mm

Length of wires stator to grommet: 40 mm

Length of wires grommet to plug: 100 mm

Other specifications:

Number of wires: 5

Number of plugs: 3

Number of pins: 5

Number of poles: 3

Wire to wire resistance:

Alternator: Yellow to Black = 0.7 ohms +/-20%

Pickup: White/Red to Black = 20 ohms +/-20%

Source: Red to Brown = 280 ohms +/-20%

• Highest grade copper windings, resistant to 200 degrees Celsius
