Stator Arctic Cat Pantera 800 ZRT 800 Thundercat 900 1000 OEM 3005-251 3004-836 3005-012 3004-128 3004-385 3004-452

Stator

Pantera 800 Carb L/C
1998 Arctic Cat Pantera 800 Carb L/C
1999 Arctic Cat Pantera 800 Carb L/C
Thundercat 1000 Carb L/C
1998 Arctic Cat Thundercat 1000 Carb L/C
1999 Arctic Cat Thundercat 1000 Carb L/C
Thundercat 900 Carb L/C
1993 Arctic Cat Thundercat 900 Carb L/C
1994 Arctic Cat Thundercat 900 Carb L/C
1995 Arctic Cat Thundercat 900 Carb L/C
1996 Arctic Cat Thundercat 900 Carb L/C
1997 Arctic Cat Thundercat 900 Carb L/C
Thundercat 900 Mountain Cat Carb L/C
1994 Arctic Cat Thundercat 900 Mountain Cat Carb L/C
1995 Arctic Cat Thundercat 900 Mountain Cat Carb L/C
1996 Arctic Cat Thundercat 900 Mountain Cat Carb L/C
1997 Arctic Cat Thundercat 900 Mountain Cat Carb L/C
ZRT 800 Carb L/C
1995 Arctic Cat ZRT 800 Carb L/C
1996 Arctic Cat ZRT 800 Carb L/C
1997 Arctic Cat ZRT 800 Carb L/C
1998 Arctic Cat ZRT 800 Carb L/C
1999 Arctic Cat ZRT 800 Carb L/C

OEM
3004-128
3004-385
3004-452
3004-836
3005-012
3005-251

Dimensions :
Interior diameter : 34 mm
Exterior diameter : 93 mm
Thickness : 15 mm
Length of wires stator to plug : 275 mm

Other specifications :
Number of wires : 8
Number of plugs : 3
Number of pins : 9

Wire to wire resistance :
Alternator : Yellow to Yellow = 0.1 ohms +/-20%
Source 1 : Green to Black = 25 ohms +/-20%
Source 2 : Green to White = 447 ohms +/-20%
